Intel Xeon E5-1620V2 processor 3.7 GHz 10 MB Smart Cache
- Intel® Xeon® Processor E5-1620 v2 (10M Cache
- 3.70 GHz)
- Photos are indicative and may differ. SpareIT tries to represent this as correctly as possible.
Disclaimer:
Product photos and specifications are made available by Universal Databases and are often based on new products.
When the item is a 'Refurbished product' it has been tested by us and has an A-grade condition (unless otherwise stated). Refurbished items do not include cables, software media and manuals (unless otherwise stated).
Please read the product description carefully and contact us if you have any questions.
Description
Now with greater performance, efficiency, and security to fortify your cloud solutions.
The explosive growth of unstructured data puts new demands on network and storage infrastructure and challenges your ability to deliver services such as cloud computing. IT needs to respond rapidly to new and changing business demands, scale quickly and appropriately to fluctuating workloads, accommodate business expansions, and protect your data from cybercriminals—all while keeping costs down.
Invest in an agile foundation.
The new Intel® Xeon® processor E5-2600 and E5-1600 v2 product families are at the heart of an agile, efficient data center that meets your diverse needs. Now you can deploy a more secure private cloud, quickly crunch through big data, and get the most out of your data center with greater energy efficiency.
Specifications
| Other features | |
|---|---|
| Maximum internal memory | 262144 MB |
| Cache memory | 10 MB |
| Maximum internal memory | 256 GB |
| On-board memory controller | Yes |
| Intel® Virtualization Technology (Intel® VT) | VT-d, VT-x |
| Weight & dimensions | |
| Processor package size | 52.5mm x 45mm |
| Technical details | |
| Born on date | Q3'13 |
| Bus type units | GT/s |
| Launch date | Q3'13 |
| Processor core voltage | 0.65–1.30 |
| Product name | Intel Xeon E5-1620 v2 (10M Cache, 3.70 GHz) |
| Status | Launched |
| Maximum memory | 256 GB |
| Processor brand name | Intel Xeon v2 |
| Product family | Intel Xeon Processor E5 v2 Family |
| Last change | 63903513 |
| Bus speed | 0 GT/s |
| Processor cache | 10240 KB |
| Product type | Processor |
| Supported memory types | DDR3-SDRAM |
| Algemeen | |
| Productfamilie | Xeon |
| Operational conditions | |
| Tcase | 70 °C |
| Processor special features | |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Demand Based Switching | Yes |
| Intel 64 | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® Secure Key | Yes |
| Intel TSX-NI | No |
| Intel® OS Guard | Yes |
| Conflict Free processor | No |
| Intel Enhanced Halt State | Yes |
| Intel Identity Protection Technology version | 0.00 |
| Intel Secure Key Technology version | 1.00 |
| Intel TSX-NI version | 0.00 |
| Intel® vPro™ Platform Eligibility | Yes |
| Intel® Transactional Synchronization Extensions | No |
| Intel® Turbo Boost Technology 2.0 frequency | 3.9 GHz |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | No |
| Intel® Turbo Boost Technology | 2.0 |
| Intel Flex Memory Access | No |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® Smart Cache | Yes |
| Features | |
| Commodity Classification Automated Tracking System (CCATS) | G077159 |
| Export Control Classification Number (ECCN) | 5A992C |
| Harmonized System (HS) code | 8542310001 |
| Market segment | Server |
| Scalability | 1S |
| CPU configuration (max) | 1 |
| Embedded options available | No |
| PCI Express CEM revision | 3.0 |
| Supported instruction sets | AVX |
| PCI Express configurations | x4, x8, x16 |
| PCI Express slots version | 3.0 |
| Maximum number of PCI Express lanes | 40 |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| Power | |
| VID Voltage Range | 0.65 - 1.3 V |
| Thermal Design Power (TDP) | 130 W |
| Graphics | |
| On-board graphics adapter | No |
| Memory | |
| ECC | Yes |
| Memory channels | Quad-channel |
| Memory bandwidth supported by processor (max) | 59.7 GB/s |
| Memory clock speeds supported by processor | 800,1066,1333,1600,1866 MHz |
| Memory types supported by processor | DDR3-SDRAM |
| Maximum internal memory supported by processor | 256 GB |
| Processor | |
| Processor ARK ID | 75779 |
| Processor boost frequency | 3.9 GHz |
| Bus type | QPI |
| Processor codename | Ivy Bridge EP |
| Processor cache type | Smart Cache |
| Processor cache | 10 MB |
| Processor operating modes | 64-bit |
| Processor threads | 8 |
| Processor model | E5-1620V2 |
| Processor series | Intel Xeon E5-1600 v2 |
| Cooler included | No |
| Box | No |
| Processor lithography | 22 nm |
| Component for | Server/workstation |
| Processor socket | LGA 2011 (Socket R) |
| Processor cores | 4 |
| Processor base frequency | 3.7 GHz |
| Processor family | Intel® Xeon® E5 Family |
| Processor manufacturer | Intel |
