Intel DC P3600 1.2 TB 2.5" PCI Express 3.0 NVMe
- SSD DC P3600 Series (1.2TB
- 2.5in PCIe 3.0
- 20nm
- MLC)
- Photos are indicative and may differ. SpareIT tries to represent this as correctly as possible.
Disclaimer:
Product photos and specifications are made available by Universal Databases and are often based on new products.
When the item is a 'Refurbished product' it has been tested by us and has an A-grade condition (unless otherwise stated). Refurbished items do not include cables, software media and manuals (unless otherwise stated).
Please read the product description carefully and contact us if you have any questions.
Description
Breakthrough performance
The Intel Solid-State Drive Data Center Family for PCIe brings extreme data throughput directly to Intel Xeon processors with up to six times faster data transfer speed than 6 Gbps SAS/SATA SSDs. The performance of a single drive from the Intel SSD Data Center Family for PCIe, specifically the Intel Solid-State Drive Data Center P3700 Series (460K IOPS), can replace the performance of 7 SATA SSDs aggregated through a host bus adapter (HBA) (approximately 500K IOPS).
Modernizes data center storage
Intel led the industry in creation of a new Non-Volatile Memory Express (NVMe) storage interface standard. NVMe overcomes SAS/SATA SSD performance limitations by optimizing hardware and software to take full advantage of NVM SSD technology.
Comprehensive solution
Intel is driving transition to NVMe SSDs by providing a comprehensive product line, enabling extensive system compatibility, delivering Intel drivers as well as supporting industry driver development, and completing numerous industry standard compliance certifications.
Proven quality and reliability
Intel SSD Data Center Family for PCIe devices are based on Intel-developed controller, firmware, and leading manufacturing process NAND flash memory. Rigorous qualification and compatibility testing ensures a highly reliable SSD. The Intel SSD Data Center Tool provides a powerful set of management capabilities.
Specifications
| Other features | |
|---|---|
| Drive capacity | 1.2 TB |
| Product brief URL | http://www.intel.com/content/dam/www/public/us/en/documents/product-briefs/intel-ssd-dc-family-for-pcie-brief.pdf |
| SSD power consumption (idle) | 4W |
| SSD shock | 1000G/0.5msec |
| SSD weight | 125gm |
| Last change | 63903513 |
| Born on date | Q2'14 |
| Product name | Intel SSD DC P3600 Series (1.2TB, 2.5in PCIe 3.0, 20nm, MLC) |
| Processor lithography | 20 nm |
| Internal | Yes |
| Technical details | |
| Status | Discontinued |
| Launch date | Q2'14 |
| Sequential reading | 2600 MB/s |
| Sequential writing speed | 1250 MB/s |
| SSD endurance rating | 6.57 PBW (JEDEC Workload) |
| SSD power consumption (active) | 15W (write), 9W (read) |
| Weight & dimensions | |
| Weight | 125 g |
| Height | 15 mm |
| Technical details | |
| Compliance certificates | RoHS |
| Features | |
| Harmonized System (HS) code | 84717070 |
| Operational conditions | |
| Maximum operating altitude | 3048 m |
| Maximum non-operating altitude | 12192 m |
| Operating shock | 1000 G |
| Non-operating vibration | 3.13 G |
| Operating vibration | 2.17 G |
| Storage temperature (T-T) | -55 - 95 °C |
| Operating temperature (T-T) | 0 - 70 °C |
| Brand-specific features | |
| Intel High Endurance Technology (HET) | Yes |
| Power | |
| Power consumption (idle) | 4 W |
| Design | |
| Product codename | Fultondale |
| Product series | Intel DC P3600 |
| Product family | Data center SSD |
| Certification | UL, CE, C-Tick, BSMI, KCC, Microsoft WHQL, VCCI |
| Market segment | Server |
| Product colour | Grey |
| SSD form factor | 2.5" |
| Performance | |
| SSD ARK ID | 80991 |
| SSD usage tag | Data center |
| Mean time between failures (MTBF) | 2000000 h |
| Uncorrectable Bit Error Rate (UBER) | < 1 per 10^17 bits read |
| SSD temperature monitoring | Yes |
| Enhanced Power Loss Data Protection technology | Yes |
| End-to-End Data Protection | Yes |
| Wi-Fi | No |
| Random write (100% span) | 50000 IOPS |
| Random read (100% span) | 450000 IOPS |
| Random write (8KB) | 27000 IOPS |
| Random read (8KB) | 260000 IOPS |
| Random write (4KB) | 50000 IOPS |
| Random read (4KB) | 450000 IOPS |
| PCI Express interface data lanes | x4 |
| Lithography | 20 nm |
| Latency (write) | 20 µs |
| Latency (read) | 20 µs |
| NVM Express (NVMe) supported | Yes |
| Write speed | 1250 MB/s |
| Read speed | 2600 MB/s |
| HDD interface | PCI Express 3.0 |
| SSD capacity | 1.2 TB |
