718162-B21 HPE 1.2TB 6G SAS 10K SFF (2.5in) SC DP ENT HDD - G8 G9 G10
to € 30,00 Excl. VAT
- 1.2TB 6G SAS
- hot-plug dual-port SAS hard disk drive
- 6Gb/sec transfer rate
- 10,000 RPM
- 2.5-inch small form factor (SFF)
- Enterprise
- SmartDrive Carrier (SC)
- For use with Proliant Gen8 Gen9 Gen10 (G8 G9 G10) servers
- Photos are indicative and may differ. SpareIT tries to represent this as correctly as possible.
Disclaimer:
Product photos and specifications are made available by Universal Databases and are often based on new products.
When the item is a 'Refurbished product' it has been tested by us and has an A-grade condition (unless otherwise stated). Refurbished items do not include cables, software media and manuals (unless otherwise stated).
Please read the product description carefully and contact us if you have any questions.
Description
Option Part Number: 718162-B21
Spare Part Number: 718292-001
Model Number: EG1200FDJYT
Model Number: EG1200FDNJT
Model Number: EG1200JEHMC
Model Number: EG1200JEMDA
Model Number: EG1200JETKC
Model Number: EG001200JWFUT
Assembly Number: 718159-002
Assembly Number: 726480-001
Assembly Number: 768788-004
Assembly Number: 781514-002
Assembly Number: 796365-004
Assembly Number: 872283-003
HPE GPN: 693651-004
General
Device Type: Hard Drive - Hot-Swap
Capacity: 1.2 TB
Form Factor: 2.5 inch SFF
Interface: SAS 6Gbps
Carrier Type: Smart Carrier
Bytes per Sector: 512
Bundled with: HPE SmartDrive carrier
Performance
Drive Transfer Rate: 600 MBps (external)
Seek Time: 8.9 ms (max)
Track-to-Track Seek Time: 0.3 ms
Average Latency: 4.6 ms
Spindle Speed: 10000 RPM
Expansion & Connectivity
Interfaces: 2 x SAS 6Gb/s
Compatible Bay: 2.5" SFF
Dimensions & Weight
Width: 3.00 inch
Depth: 4.70 inch
Height: 0.60 inch
Weight: 25.57 oz
Environmental Parameters
Min Operating Temperature: 50 °F
Max Operating Temperature: 95 °F
Compatibility Information
Designed For
HPE ProLiant BL Series: BL460c Gen8 (2.5 inch), BL660c Gen8 (2.5 inch), BL660c Gen8 Performance (2.5 inch), BL660c Gen9 (2.5 inch)
HPE ProLiant DL Series: DL180 Gen9 (2.5 inch), DL180 Gen9 Base (2.5 inch), DL180 Gen9 Entry (2.5 inch), DL180 Gen9 Storage (2.5 inch), DL20 Gen9 (2.5 inch), DL20 Gen9 Entry (2.5 inch), DL20 Gen9 Performance (2.5 inch), DL320e Gen8 (2.5 inch), DL320e Gen8 Base (2.5 inch), DL320e Gen8 Entry (2.5 inch), DL320e Gen8 Performance (2.5 inch), DL320e Gen8 v2 (2.5 inch), DL320e Gen8 v2 Base (2.5 inch), DL320e Gen8 v2 Performance (2.5 inch), DL360 Gen9 CMS (2.5 inch), DL360 Gen9 Entry (2.5 inch), DL360p Gen8 (2.5 inch), DL360p Gen8 CMS (2.5 inch), DL360p Gen8 Performance (2.5 inch), DL360p Gen8 Special Server (2.5 inch), DL380 Gen9 (2.5 inch), DL380 Gen9 Base (2.5 inch), DL380 Gen9 Entry (2.5 inch), DL380 Gen9 Performance (2.5 inch), DL380p Gen8 Performance (2.5 inch), DL385p Gen8 (2.5 inch), DL385p Gen8 Dedicated Workload (2.5 inch), DL385p Gen8 Entry (2.5 inch), DL385p Gen8 Storage (2.5 inch), DL385p Gen8 Storage Centric (2.5 inch), DL560 Gen8 (2.5 inch), DL560 Gen8 Base (2.5 inch), DL560 Gen8 Entry (2.5 inch), DL560 Gen8 Performance (2.5 inch), DL560 Gen9 (2.5 inch), DL560 Gen9 Base (2.5 inch), DL560 Gen9 Entry (2.5 inch), DL560 Gen9 Performance (2.5 inch), DL580 Gen9 (2.5 inch), DL580 Gen9 Database (2.5 inch), DL580 Gen9 SAP HANA Scale-up Base Configuration (2.5 inch)
HPE ProLiant ML Series: ML110 Gen9 (2.5 inch), ML110 Gen9 Base (2.5 inch), ML110 Gen9 Entry (2.5 inch), ML30 Gen9 (2.5 inch), ML30 Gen9 Base (2.5 inch), ML30 Gen9 Performance (2.5 inch), ML310e Gen8 (2.5 inch), ML310e Gen8 Base (2.5 inch), ML310e Gen8 Entry (2.5 inch), ML310e Gen8 Performance (2.5 inch), ML310e Gen8 v2 (2.5 inch), ML310e Gen8 v2 Base (2.5 inch), ML310e Gen8 v2 Entry (2.5 inch), ML310e Gen8 v2 Performance (2.5 inch), ML350 Gen9 (2.5 inch), ML350 Gen9 Base (2.5 inch), ML350 Gen9 Entry (2.5 inch), ML350 Gen9 Performance (2.5 inch), ML350e Gen8 (2.5 inch), ML350e Gen8 v2 (2.5 inch), ML350p Gen8 (2.5 inch), ML350p Gen8 Special Server (2.5 inch)
HPE ProLiant SL Series: SL250s Gen8 Left Tray (2.5 inch), SL250s Gen8 Right Tray (2.5 inch)
HPE ProLiant WS Series: WS460c Gen8 (2.5 inch), WS460c Gen9 Graphics (2.5 inch), WS460c Gen9 Graphics Expansion (2.5 inch)
HPE ProLiant XL Series: XL170r Gen9 (2.5 inch), XL190r Gen9 (2.5 inch)
Specifications
| Other features | |
|---|---|
| Data transfer rate | 6 Gbit/s |
| Weight & dimensions | |
| Weight | 450 g |
| Height | 228.6 mm |
| Depth | 117.6 mm |
| Width | 177.8 mm |
| Power | |
| Operating voltage | 5 V |
| Hard drive | |
| Component for | Server/workstation |
| HDD form factor | 2.5" |
| HDD speed | 10000 RPM |
| Type | HDD |
| HDD interface | SAS |
| HDD capacity | 1.2 TB |
